06-13 Suzuki Grand Vitara (3.2) CV Axle Assembly - Front Left
SPECIFICATIONS
ABS Tone Ring Included
No
Boot Material
Neoprene
Compressed Length
22.05
Inboard Spline Quantity
0
Outboard Spline Quantity
28
Seal Diameter
2.29
Boot Color
Black
California Proposition 65
Yes
Inboard Joint Type
Flange
Outboard Joint Type
Conventional
Prop 65 Yes/No
Yes
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2012-2012 | Suzuki | Grand Vitara | Ultimate Adventure Edition | Front Left |
2010-2013 | Suzuki | Grand Vitara | Limited | Front Left |
2010-2010 | Suzuki | Grand Vitara | GLS, JLX | Front Left |
2009-2013 | Suzuki | Grand Vitara | Premium | Front Left |
2006-2010 | Suzuki | Grand Vitara | XSport | Front Left |
2006-2009 | Suzuki | Grand Vitara | Luxury | Front Left |
2006-2008 | Suzuki | Grand Vitara | Base | Front Left |
2006-2006 | Suzuki | Grand Vitara | Premium | Front Left |
