Mercedes-Benz (3.0, 3.5 - 4WD/AWD) CV Axle Assembly - Front Left
SPECIFICATIONS
ABS Tone Ring Included
No
Axle Nut Length
21.5
Axle Nut Thread Size
M24×1.5
Boot Color
Black
California Proposition 65
Yes
Inboard Joint Type
Male
Outboard Joint Type
Conventional
Prop 65 Yes/No
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
32
Axle Nut Type
Hex
Boot Material
Neoprene
Compressed Length
665
Inboard Spline Quantity
37
Outboard Spline Quantity
30
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2010-2011 | Mercedes-Benz | ML350 | Front Left | |
2010-2010 | Mercedes-Benz | ML350 | Front Left | |
2010-2012 | Mercedes-Benz | GL350 | Front Left | |
2010-2011 | Mercedes-Benz | ML450 | Front Left | |
2008-2011 | Mercedes-Benz | ML550 | Front Left | |
2008-2012 | Mercedes-Benz | GL550 | Front Left | |
2007-2012 | Mercedes-Benz | GL450 | Front Left | |
2007-2009 | Mercedes-Benz | GL320 | Front Left | |
2007-2009 | Mercedes-Benz | ML320 | Front Left | |
2006-2009 | Mercedes-Benz | ML350 | Front Left | |
2006-2007 | Mercedes-Benz | ML500 | Front Left |
