90-93 Mazda Miata CV Axle Assembly
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Thread Size
M22×1.5
Boot Color
Black
California Proposition 65
Yes
Inboard Joint Type
Flange
Outboard Joint Type
Conventional
Prop 65 Yes/No
Yes
ABS Tone Ring Tooth Quantity
44
Axle Nut Length
0.83
Axle Nut Type
Hex
Boot Material
Neoprene
Compressed Length
25.24
Inboard Spline Quantity
0
Outboard Spline Quantity
26
Seal Diameter
2.20
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
1990-1993 | Mazda | Miata | Rear Left, Rear Right |
