Buick, Oldsmobile, Pontiac (2.3, 2.5, 3.1, 3.3) CV Axle Assembly - Front Left
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Thread Size
M20×1.5
Boot Color
Black
California Proposition 65
Yes
Inboard Joint Type
Female
Outboard Joint Type
Conventional
Prop 65 Yes/No
Yes
ABS Tone Ring Tooth Quantity
48
Axle Nut Length
0.79
Axle Nut Type
Hex
Boot Material
Neoprene
Compressed Length
20.37
Inboard Spline Quantity
34
Outboard Spline Quantity
33
Seal Diameter
1.87
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
1995-1995 | Pontiac | Grand Am | SE | Front Left |
1995-1995 | Oldsmobile | Achieva | SL, S | Front Left |
1994-1995 | Pontiac | Grand Am | GT | Front Left |
1994-1994 | Buick | Skylark | Custom | Front Left |
1993-1993 | Buick | Skylark | Limited | Front Left |
1992-1993 | Oldsmobile | Achieva | SL, S | Front Left |
1992-1992 | Oldsmobile | Achieva | SC | Front Left |
1992-1993 | Pontiac | Grand Am | Front Left | |
1991-1991 | Buick | Skylark | Luxury Edition, Custom | Front Left |
1991-1991 | Oldsmobile | Cutlass Calais | Base, , GT | Front Left |
1991-1991 | Pontiac | Grand Am | Front Left |
