Toyota (RWD) Wheel Bearing and Hub Assembly - Front
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Roller
Brake Pilot Diameter
97
Flange Bolt Hole Quantity
6
Flange Offset
68.5
Prop 65 Yes/No
Yes
Wheel Stud Thread Size
M14x1.5
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
139.7
California Proposition 65
Yes
Flange Diameter
178.9
Hub Pilot Diameter
106
Wheel Pilot Diameter
95
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2023-2025 | Toyota | Sequoia | Capstone, Limited, Platinum, SR5 | Front |
2022-2025 | Toyota | Tundra | 1794 Edition, Limited, SR, SR5, Platinum | Front |
