19-23 Ford Transit Connect Wheel Bearing and Hub Assembly - Rear
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
44
Anti Lock Braking System Type
Wheel speed sensor
Bearing Type
Ball
Bolt Thread Pitch
M14x1.5
Brake Pilot Diameter
63.5
Driven Type
Non-driven
Flange Bolts Included
No
Flange Included
Yes
Hub Pilot Diameter
81.4
Prop 65 Yes/No
Yes
Wheel Stud Quantity
5
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
107.95
Bolts Included
No
California Proposition 65
Yes
Flange Bolt Hole Quantity
4
Flange Diameter
136.5
Flange Offset
73.2
Placement
Rear
Wheel Pilot Diameter
63.2
Wheel Studs Included
Yes
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2019-2023 | Ford | Transit Connect | Rear |
