BMW Wheel Bearing and Hub Assembly - Front
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Bolt Thread Pitch
M14x1.25
Brake Pilot Diameter
79
Driven Type
Non-driven
Flange Bolts Included
No
Flange Included
Yes
Hub Pilot Diameter
90
Wheel Pilot Diameter
72.5
Wheel Studs Included
No
Anti Lock Braking System
Yes
Bearing Generation
Gen 3(solid)
Bolt Circle Diameter
120
Bolts Included
No
California Proposition 65
Yes
Flange Bolt Hole Quantity
4
Flange Diameter
145
Flange Offset
51
Prop 65 Yes/No
Yes
Wheel Stud Quantity
5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2015-2017 | BMW | M3 | Front | |
2015-2015 | BMW | M4 | Front |
