Mitsubishi (2.4 - FWD) Wheel Hub - Front
Experience the power of GSP's Wheel Hubs, engineered to redefine performance and durability. Leveraging our global expertise as a leading automotive manufacturing, we have meticulously crated each wheel hub from steel sourced from pre-approved mills, ensuring exceptional cleanliness and adherence to the highest standards.
SPECIFICATIONS
Anti Lock Braking System
No
Brake Pilot Diameter
69
Flange Bolt Hole Quantity
5
Flange Offset
39
Hub Pilot Diameter
40
Spline Quantity
25
Wheel Stud Thread Size
M12x1.5
Bolt Circle Diameter
114.3
California Proposition 65
Yes
Flange Diameter
142.5
Height
92.5
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
67
FEATURES & BENEFITS
● Designed with raw steel material that meets or exceeds standards to produce a long-lasting service life.
● All hub assemblies go through a vacuum vulcanization process to enhance the structural integrity of the seal and rubber components.
● Ball bearings are spaced precisely to the appropriate clearance for smooth rotation and abrasion resistance.
● High quality rubber optimizes the seals performance and durability against high-temperatures and weathering.
● To ensure a smooth surface, free from defects, all bearing housings are manufactured with polyamides for added impact toughness and age resistance.
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2006-2006 | Mitsubishi | Lancer | LS Diamond | Front |
2005-2006 | Mitsubishi | Lancer | Ralliart | Front |
2003-2006 | Mitsubishi | Outlander | Front |
