17-18 Ford F-150 Raptor Wheel Bearing and Hub Assembly - Front
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
54
Anti Lock Braking System Type
Cable
Bearing Type
Roller
Brake Pilot Diameter
90
Flange Bolt Hole Quantity
6
Flange Offset
45.6
Prop 65 Yes/No
Yes
Wheel Stud Thread Size
M14x1.5
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
135
California Proposition 65
Yes
Flange Diameter
183
Hub Pilot Diameter
99.3
Wheel Pilot Diameter
86.8
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2017-2018 | Ford | F-150 | Raptor | Front |
