13-18 Ford Focus Electric Wheel Bearing and Hub Assembly - Rear
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
44
Anti Lock Braking System Type
Sensor
Bearing Type
Ball
Brake Pilot Diameter
63.5
Flange Bolt Hole Quantity
5
Flange Offset
63
Prop 65 Yes/No
Yes
Wheel Stud Thread Size
M12x1.5
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
108
California Proposition 65
Yes
Flange Diameter
136
Hub Pilot Diameter
81.4
Wheel Pilot Diameter
63.3
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2013-2018 | Ford | Focus | Electric | Rear |
