17-21 Honda Clarity Wheel Bearing and Hub Assembly - Rear

Part Number:

9400630

Product Type:

Hubs and Related Components

SPECIFICATIONS

ABS Tone Ring Tooth Quantity

42

Anti Lock Braking System Type

Encoder

Bearing Type

Ball

Bolt Thread Pitch

M12x1.5

Brake Pilot Diameter

64

Flange Bolt Hole Quantity

4

Flange Diameter

152

Flange Offset

61.5

Wheel Stud Quantity

5

Anti Lock Braking System

Yes

Bearing Generation

Gen 3

Bolt Circle Diameter

114.3

Bolts Included

No

Driven Type

Non-driven

Flange Bolts Included

No

Flange Included

Yes

Hub Pilot Diameter

82

Wheel Studs Included

Yes

FEATURES & BENEFITS

APPLICATIONS

Year Range
Make
Model
SubModels
Position
2017-2021
Honda
Clarity
Rear
