Cadillac, Chevrolet, GMC (RWD) Wheel Bearing and Hub Assembly - Front
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
55
Anti Lock Braking System Type
Cable
Bearing Type
Roller
Brake Pilot Diameter
78.3
Flange Bolt Hole Quantity
6
Flange Offset
49.8
Prop 65 Yes/No
Yes
Wheel Stud Thread Size
M14x1.5
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
139.7
California Proposition 65
Yes
Flange Diameter
179
Hub Pilot Diameter
99.3
Wheel Pilot Diameter
77.8
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2007-2007 | Chevrolet | Silverado 1500 Classic | Front | |
2007-2007 | Chevrolet | Silverado 1500 HD Classic | Front | |
2007-2007 | GMC | Sierra 1500 Classic | Front | |
2007-2007 | GMC | Sierra 1500 HD Classic | Front | |
2005-2006 | Chevrolet | Silverado 1500 HD | Front | |
2005-2006 | GMC | Sierra 1500 HD | Front | |
2003-2005 | Chevrolet | Astro | Front | |
2003-2013 | Chevrolet | Express 1500 | Front | |
2003-2005 | Chevrolet | Express 2500 | Front | |
2003-2013 | GMC | Savana 1500 | Front | |
2003-2005 | GMC | Savana 2500 | Front | |
2003-2005 | GMC | Safari | Front | |
2002-2006 | Cadillac | Escalade | Front | |
2002-2006 | Chevrolet | Avalanche 1500 | Front | |
2001-2003 | Chevrolet | Silverado 1500 HD | Front | |
2001-2003 | GMC | Sierra 1500 HD | Front | |
2000-2006 | Chevrolet | Suburban 1500 | Front | |
2000-2006 | Chevrolet | Tahoe | Front | |
2000-2006 | GMC | Yukon | Front | |
2000-2006 | GMC | Yukon XL 1500 | Front | |
1999-2007 | Chevrolet | Silverado 1500 | Front | |
1999-2007 | GMC | Sierra 1500 | Front |
