Wheel Bearing and Hub Assembly
SPECIFICATIONS
Anti Lock Braking System Type
Sensor
Bolt Circle Diameter
107.95
Bolts Included
No
Driven Type
Non-driven
Flange Diameter
136
Flange Offset
63
Wheel Pilot Diameter
63.1
Bearing Type
Ball
Bolt Thread Pitch
M12x1.5
Brake Pilot Diameter
63.4
Flange Bolt Hole Quantity
4
Flange Included
Yes
Hub Pilot Diameter
74
Wheel Stud Quantity
5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
---|---|---|---|---|
2007-2011 | Ford | Focus | Front |
