Scion, Subaru, Toyota Wheel Bearing and Hub Assembly Repair Kit - Rear
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Brake Pilot Diameter
58
Flange Bolt Hole Quantity
5
Flange Offset
66.5
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
56
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
100
California Proposition 65
Yes
Flange Diameter
124
Hub Pilot Diameter
84
Spline Quantity
27
Wheel Stud Thread Size
M12x1.25
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2022-2023 | Toyota | GR86 | Rear | |
2017-2020 | Toyota | 86 | Rear | |
2013-2020 | Subaru | BRZ | Rear | |
2013-2014 | Subaru | WRX STI | Rear | |
2013-2016 | Scion | FR-S | Rear | |
2012-2014 | Subaru | WRX | Rear | |
2010-2014 | Subaru | Legacy | Rear | |
2010-2014 | Subaru | Outback | Rear | |
2009-2013 | Subaru | Forester | Rear | |
2008-2014 | Subaru | Impreza | Rear |
