Ford (4WD/AWD) Wheel Bearing and Hub Assembly Repair Kit
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Brake Pilot Diameter
68
Flange Bolt Hole Quantity
5
Flange Offset
43
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
63.2
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
114.3
California Proposition 65
Yes
Flange Diameter
145.8
Hub Pilot Diameter
92.2
Spline Quantity
38
Wheel Stud Thread Size
1/2-20UNF
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2013-2019 | Ford | Police Interceptor Utility | Front, Rear | |
2011-2019 | Ford | Explorer | Rear, Front |
