Jeep Wheel Bearing and Hub Assembly - Rear
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Taper
Bolt Thread Pitch
M14x1.5
Brake Pilot Diameter
78.4
Driven Type
Driven
Flange Bolts Included
No
Flange Included
Yes
Hub Pilot Diameter
105
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
77.7
Wheel Studs Included
Yes
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
139.7
Bolts Included
No
California Proposition 65
Yes
Flange Bolt Hole Quantity
4
Flange Diameter
183
Flange Offset
47
Placement
Rear
Spline Quantity
33
Wheel Stud Quantity
6
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2023-2025 | Jeep | Grand Wagoneer L | Rear | |
2023-2025 | Jeep | Wagoneer L | Rear | |
2022-2025 | Jeep | Grand Wagoneer | Rear | |
2022-2025 | Jeep | Wagoneer | Rear |
