Cadillac, Chevrolet, GMC (4WD/AWD) Wheel Bearing and Hub Assembly Repair Kit
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
55
Anti Lock Braking System Type
Cable
Bearing Type
Roller
Brake Pilot Diameter
78.4
Flange Bolt Hole Quantity
6
Flange Offset
50
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
77.8
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
139.7
California Proposition 65
Yes
Flange Diameter
179
Hub Pilot Diameter
99.3
Spline Quantity
33
Wheel Stud Thread Size
M14x1.5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2007-2007 | Chevrolet | Silverado 1500 Classic | Front | |
2007-2007 | Chevrolet | Silverado 1500 HD Classic | Front | |
2007-2007 | GMC | Sierra 1500 Classic | Front | |
2007-2007 | GMC | Sierra 1500 HD Classic | Front | |
2003-2006 | Cadillac | Escalade ESV | Front | |
2003-2014 | Chevrolet | Express 1500 | Front | |
2003-2005 | Chevrolet | Express 2500 | Front, Rear | |
2003-2014 | GMC | Savana 1500 | Front | |
2003-2005 | GMC | Savana 2500 | Rear, Front | |
2002-2006 | Cadillac | Escalade EXT | Front | |
2002-2006 | Cadillac | Escalade | Front | |
2002-2006 | Chevrolet | Avalanche 1500 | Front | |
2000-2006 | Chevrolet | Suburban 1500 | Front | |
2000-2006 | Chevrolet | Tahoe | Front | |
2000-2006 | GMC | Yukon | Front | |
2000-2006 | GMC | Yukon XL 1500 | Front | |
1999-2007 | Chevrolet | Silverado 1500 | Front | |
1999-2006 | GMC | Sierra 1500 | Front |
