23-25 Volvo XC40 Wheel Bearing and Hub Assembly - Front
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Bolt Thread Pitch
M12×1.75
Brake Pilot Diameter
63.5
Driven Type
Driven
Flange Bolts Included
No
Flange Included
Yes
Hub Pilot Diameter
84.5
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
63.3
Wheel Studs Included
No
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
108
Bolts Included
No
California Proposition 65
Yes
Flange Bolt Hole Quantity
3
Flange Diameter
136
Flange Offset
47
Placement
Front
Spline Quantity
36
Wheel Stud Quantity
5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2023-2025 | Volvo | XC40 | Front |
