Chevrolet (1.4, 1.6, 1.8) Wheel Bearing and Hub Assembly - Front
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Brake Pilot Diameter
60
Flange Bolt Hole Quantity
5
Flange Offset
42
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
56.5
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
105
California Proposition 65
Yes
Flange Diameter
136
Hub Pilot Diameter
86.3
Spline Quantity
33
Wheel Stud Thread Size
M12x1.5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2017-2023 | Chevrolet | Bolt EV | Front | |
2016-2019 | Chevrolet | Volt | Front | |
2016-2016 | Chevrolet | Cruze Limited | Front | |
2010-2019 | Chevrolet | Cruze | Front |
