Hyundai, Kia Wheel Bearing and Hub Assembly - Front
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Brake Pilot Diameter
69
Flange Bolt Hole Quantity
5
Flange Offset
53.5
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
67
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
114.3
California Proposition 65
Yes
Flange Diameter
139.2
Hub Pilot Diameter
91.8
Spline Quantity
30
Wheel Stud Thread Size
M12x1.5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2025-2025 | Hyundai | Tucson | Front | |
2024-2024 | Hyundai | Tucson | Blue Hybrid, Limited, Limited Hybrid, Limited Plug-In Hybrid, SE, SEL, SEL Convenience Hybrid, SEL Plug-In Hybrid, XRT | Front |
2023-2023 | Kia | Sportage | Front | |
2022-2022 | Kia | Sportage | Nightfall Edition | Front |
2022-2023 | Hyundai | Tucson | Front | |
2022-2023 | Hyundai | Kona N | Front | |
2021-2023 | Kia | K5 | Front | |
2021-2022 | Hyundai | Veloster N | Front | |
2020-2025 | Hyundai | Sonata | Front |
