17-19 Cadillac ATS (2.0, 3.6 - AWD) Wheel Bearing and Hub Assembly
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Bolt Thread Pitch
M12×1.75
Brake Pilot Diameter
70.6
Driven Type
Driven
Flange Bolts Included
No
Flange Included
Yes
Hub Pilot Diameter
91.3
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
70.1
Wheel Studs Included
Yes
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
115
Bolts Included
No
California Proposition 65
Yes
Flange Bolt Hole Quantity
3
Flange Diameter
146
Flange Offset
42
Placement
Front
Spline Quantity
30
Wheel Stud Quantity
5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2018-2019 | Cadillac | ATS | Base, Luxury, Premium Luxury, Premium Performance | Front, Rear |
2017-2017 | Cadillac | ATS | Base, Luxury, Premium Luxury, Premium Performance | Rear, Front |
