Jeep (5.7 - 4WD/AWD/RWD) Wheel Bearing and Hub Assembly
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Bearing Generation
Gen 3
Bolt Circle Diameter
127
Bolts Included
Yes
Driven Type
Driven
Flange Diameter
165
Flange Offset
63.5
Hub Pilot Diameter
85
Wheel Pilot Diameter
71.4
Anti Lock Braking System Type
Tone Ring
Bearing Type
Ball
Bolt Thread Pitch
1/2-20UNF
Brake Pilot Diameter
71.9
Flange Bolt Hole Quantity
4
Flange Included
Yes
Height
158
Spline Quantity
29
Wheel Stud Quantity
5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
---|---|---|---|---|
2008-2008 | Jeep | Commander | Overland | |
2006-2007 | Jeep | Commander | Limited Premium | |
2005-2010 | Jeep | Commander | Rear | |
2005-2010 | Jeep | Grand Cherokee | Rear |
