13-25 Mazda CX-5 (2.0, 2.2, 2.5 - AWD) Wheel Bearing and Hub Assembly - Rear
SPECIFICATIONS
Anti Lock Braking System
No
Bearing Type
Ball
Brake Pilot Diameter
68
Flange Bolt Hole Quantity
5
Flange Offset
57
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
67
Bearing Generation
Gen 3
Bolt Circle Diameter
114.3
California Proposition 65
Yes
Flange Diameter
139
Hub Pilot Diameter
82.9
Spline Quantity
28
Wheel Stud Thread Size
M12x1.5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2022-2025 | Mazda | CX-5 | Rear | |
2021-2021 | Mazda | CX-5 | Carbon Edition, Carbon Edition Turbo | Rear |
2020-2021 | Mazda | CX-5 | Signature | Rear |
2019-2021 | Mazda | CX-5 | Grand Touring, Grand Touring Reserve, Sport, Touring | Rear |
2019-2019 | Mazda | CX-5 | Signature | Rear |
2017-2018 | Mazda | CX-5 | Sport | Rear |
2017-2017 | Mazda | CX-5 | Grand Select | Rear |
2016-2016 | Mazda | CX-5 | Sport | Rear |
2015-2015 | Mazda | CX-5 | Sport | Rear |
2013-2018 | Mazda | CX-5 | Grand Touring, Touring | Rear |
2013-2014 | Mazda | CX-5 | Sport | Rear |
