Hyundai, Kia (2.5 - AWD) Wheel Bearing and Hub Assembly - Rear
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
47
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Brake Pilot Diameter
76
Flange Bolt Hole Quantity
5
Flange Offset
53.5
Prop 65 Yes/No
Yes
Wheel Pilot Diameter
67
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
114.3
California Proposition 65
Yes
Flange Diameter
139
Hub Pilot Diameter
86
Spline Quantity
27
Wheel Stud Thread Size
M12x1.5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2025-2025 | Hyundai | Tucson | N Line Hybrid, SEL Convenience | Rear |
2024-2025 | Hyundai | Sonata | SEL | Rear |
2023-2023 | Kia | Sportage | EX, Hybrid EX, Hybrid LX, Hybrid SX Prestige, LX, Plug-In Hybrid X-Line Prestige, Plug-In Hybrid X-Line, SX, SX Prestige, X-Line, X-Pro, X-Pro Prestige | Rear |
2022-2022 | Kia | Sportage | Nightfall Edition | Rear |
2022-2025 | Hyundai | Tucson | Blue Hybrid, Limited, Limited Hybrid, Limited Plug-In Hybrid, SE, SEL, SEL Convenience Hybrid, SEL Plug-In Hybrid, XRT | Rear |
2022-2023 | Hyundai | Tucson | N Line | Rear |
2021-2023 | Kia | K5 | GT-Line, LXS | Rear |
