Lexus, Toyota (2.7, 3.3, 3.5 - AWD) Wheel Bearing and Hub Assembly - Rear

Part Number:

9326036

Product Type:

Hubs and Related Components

SPECIFICATIONS

ABS Tone Ring Tooth Quantity

-

Bearing Generation

Gen 3

Bolt Circle Diameter

114.3

Bolts Included

No

Driven Type

Driven

Flange Bolts Included

No

Flange Included

Yes

Hub Pilot Diameter

83.8

Anti Lock Braking System

No

Bearing Type

Ball

Bolt Thread Pitch

M12x1.5

Brake Pilot Diameter

62

Flange Bolt Hole Quantity

4

Flange Diameter

152

Flange Offset

72

FEATURES & BENEFITS

APPLICATIONS

Year Range
Make
Model
SubModels
Position
2009-2016
Toyota
Venza
Rear
2008-2014
Toyota
Highlander
Rear
2007-2008
Lexus
RX350
Rear
2006-2008
Lexus
RX400h
Rear
2004-2007
Toyota
Highlander
Rear
2004-2006
Lexus
RX330
Rear
