06-13 Suzuki Grand Vitara Suspension Shock Absorber - Front Left
SPECIFICATIONS
Body Color
Black
Boot Included
No
Compressed Length
377
Cylinder Outside Diameter
51
Lower Mount Type
Sealed strut
Prop 65 Yes/No
Yes
Shock Stroke
203
Type
Gas Charged
Upper Mount Type
Stem
Body Material
Steel
California Proposition 65
Yes
Cylinder Material
Steel
Extended Length
580
Mounting Hardware Included
Yes
Rod Diameter
22
Travel Length
203
Upper Mount Stem Thread Size
M14×1.5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2012-2013 | Suzuki | Grand Vitara | JX, Urban | Front Left |
2012-2012 | Suzuki | Grand Vitara | Ultimate Adventure Edition, Himalaya, Base | Front Left |
2011-2013 | Suzuki | Grand Vitara | JLX-L | Front Left |
2011-2011 | Suzuki | Grand Vitara | JX | Front Left |
2010-2013 | Suzuki | Grand Vitara | Limited, GLS, Premium | Front Left |
2010-2010 | Suzuki | Grand Vitara | JX, Limited | Front Left |
2009-2009 | Suzuki | Grand Vitara | Luxury, JA, Premium, JX, Base | Front Left |
2009-2013 | Suzuki | Grand Vitara | GL, JLX, Base, Premium | Front Left |
2009-2010 | Suzuki | Grand Vitara | JLX, GLS, XSport | Front Left |
2008-2008 | Suzuki | Grand Vitara | JLX, Limited, JA, JX | Front Left |
2007-2008 | Suzuki | Grand Vitara | GL, GLS, SWT | Front Left |
2006-2008 | Suzuki | Grand Vitara | Base, Luxury, XSport | Front Left |
2006-2006 | Suzuki | Grand Vitara | GL, GLS, Premium | Front Left |
