Volvo CV Axle Assembly - Front Left
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
No
Compressed Length
526
Inboard Spline Quantity
26
Outboard Spline Quantity
36
ABS Tone Ring Tooth Quantity
48
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2008-2009 | Volvo | S60 | T5 | Front Left |
2006-2007 | Volvo | V70 | 2.4 | Front Left |
2005-2005 | Volvo | V70 | T5 | Front Left |
2004-2009 | Volvo | S60 | 2.5T | Front Left |
2004-2005 | Volvo | S60 | R, 2.5T AWD | Front Left |
2004-2004 | Volvo | S60 | 2.4 | Front Left |
2004-2007 | Volvo | V70 | 2.5T | Front Left |
2004-2006 | Volvo | V70 | R | Front Left |
2004-2004 | Volvo | V70 | 2.4, 2.5T AWD | Front Left |
2002-2003 | Volvo | S60 | AWD | Front Left |
2002-2003 | Volvo | V70 | AWD | Front Left |
2001-2004 | Volvo | S60 | T5 | Front Left |
2001-2003 | Volvo | S60 | 2.4T, Base | Front Left |
2001-2004 | Volvo | V70 | T5 | Front Left |
2001-2003 | Volvo | V70 | Base, 2.4T | Front Left |
