CV Axle Assembly
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
32
Axle Nut Type
Hex
Compressed Length
36.57
Inboard Spline Quantity
20
Outboard Spline Quantity
26
ABS Tone Ring Tooth Quantity
48
Axle Nut Length
20
Axle Nut Thread Size
M22×1.5
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2003-2006 | Pontiac | Vibe | GT | Front Right |
2003-2006 | Toyota | Matrix | XRS | Front Right |
