Chevrolet, Pontiac (1.0) CV Axle Assembly - Front Left
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
30
Axle Nut Type
Hex
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
ABS Tone Ring Tooth Quantity
40
Axle Nut Length
20
Axle Nut Thread Size
M18×1.5
Boot Color
Black
Compressed Length
22.13
Inboard Spline Quantity
22
Outboard Spline Quantity
23
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2011-2015 | Chevrolet | Matiz | Front Left | |
2004-2010 | Pontiac | Matiz | Base | Front Left |
