Subaru (Sedan) CV Axle Assembly
SPECIFICATIONS
ABS Tone Ring Included
NO
Axle Nut Length
17.5
Axle Nut Thread Size
M24×1.5
Boot Material
Neoprene
Inboard Joint Type
Female
Outboard Joint Type
Conventional
Axle Nut Included
Yes
Axle Nut Socket Size
35.7
Axle Nut Type
Hex
Compressed Length
693
Inboard Spline Quantity
25
Outboard Spline Quantity
30
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
1988-1989 | Subaru | GL | Turbo | Front Left, Front Right |
1988-1989 | Subaru | RX | Front Right, Front Left | |
1987-1987 | Subaru | XT | GL | Front Left, Front Right |
1985-1985 | Subaru | GL | Turbo | Front Left, Front Right |
1985-1989 | Subaru | GL-10 | Turbo | Front Left, Front Right |
1985-1987 | Subaru | RX | Front Right, Front Left | |
1985-1987 | Subaru | XT | GL-10 Turbo | Front Left, Front Right |
