Subaru (Sedan/Wagon - 4WD) CV Axle Assembly - Front
SPECIFICATIONS
ABS Tone Ring Included
No
Axle Nut Length
18
Axle Nut Thread Size
M24×1.5
Boot Color
Black
California Proposition 65
Yes
Inboard Joint Type
Female
Outboard Joint Type
Conventional
Prop 65 Yes/No
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
36
Axle Nut Type
Hex
Boot Material
Neoprene
Compressed Length
27
Inboard Spline Quantity
23
Outboard Spline Quantity
30
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
1994-1994 | Subaru | Loyale | Front | |
1990-1993 | Subaru | Loyale | Front | |
1988-1989 | Subaru | GL | Turbo | Front |
1988-1989 | Subaru | RX | Front | |
1988-1991 | Subaru | XT | GL | Front |
1987-1989 | Subaru | DL | Front | |
1987-1987 | Subaru | XT | GL, GL-10 | Front |
1985-1985 | Subaru | GL | Turbo | Front |
1985-1989 | Subaru | GL-10 | Front | |
1985-1987 | Subaru | RX | Front | |
1985-1988 | Subaru | XT | DL | Front |
1985-1986 | Subaru | XT | GL | Front |
