03-10 Peugeot 307 (2.0) CV Axle Assembly - Front Right
SPECIFICATIONS
ABS Tone Ring Included
NO
Axle Nut Length
17.5
Axle Nut Thread Size
M24×1.5
Boot Color
Black
Compressed Length
36.42
Inboard Spline Quantity
24
Outboard Spline Quantity
25
Axle Nut Included
Yes
Axle Nut Socket Size
35.7
Axle Nut Type
Hex
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2010-2010 | Peugeot | 307 | X-Line | Front Right |
2008-2009 | Peugeot | 307 | CC Roland Garros | Front Right |
2007-2009 | Peugeot | 307 | SW X-Line | Front Right |
2007-2008 | Peugeot | 307 | Feline, XS Pack, CC Dynamique | Front Right |
2007-2007 | Peugeot | 307 | XS-line, SW Pack | Front Right |
2006-2008 | Peugeot | 307 | X-Line | Front Right |
2006-2007 | Peugeot | 307 | Pack | Front Right |
2005-2008 | Peugeot | 307 | XSI | Front Right |
2005-2005 | Peugeot | 307 | X-Design | Front Right |
2004-2007 | Peugeot | 307 | CC | Front Right |
2004-2005 | Peugeot | 307 | Base | Front Right |
2003-2008 | Peugeot | 307 | XR | Front Right |
2003-2007 | Peugeot | 307 | XS | Front Right |
2003-2005 | Peugeot | 307 | XR Break, XT | Front Right |
2003-2004 | Peugeot | 307 | XT Break | Front Right |
