00-01 Nissan Maxima CV Axle Assembly - Front Left

Part Number:

241519

Product Type:

CV Components

​

SPECIFICATIONS

ABS Tone Ring Included

Yes

Axle Nut Included

Yes

Axle Nut Socket Size

32

Axle Nut Type

Hex

Compressed Length

25.2

Inboard Spline Quantity

29

Outboard Spline Quantity

29

ABS Tone Ring Tooth Quantity

44

Axle Nut Length

23.5

Axle Nut Thread Size

M24×1.5

Boot Material

Neoprene

Inboard Joint Type

Male

Outboard Joint Type

Conventional

FEATURES & BENEFITS

​

APPLICATIONS

Year Range
Make
Model
SubModels
Position
2001-2001
Nissan
Maxima
SE, GXE
Front Left
2000-2000
Nissan
Maxima
SE
Front Left
