Mercedes-Benz (5.5) CV Axle Assembly
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
36
Axle Nut Type
Hex
Compressed Length
31.18
Inboard Spline Quantity
32
Outboard Spline Quantity
30
ABS Tone Ring Tooth Quantity
48
Axle Nut Length
24
Axle Nut Thread Size
M24×1.5
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2004-2005 | Mercedes-Benz | ML350 | Base | Rear Left, Rear Right |
2004-2005 | Mercedes-Benz | ML500 | Base | Rear Left, Rear Right |
2003-2003 | Mercedes-Benz | ML350 | Rear Right, Rear Left | |
2002-2003 | Mercedes-Benz | ML55 AMG | Rear Right, Rear Left | |
2002-2003 | Mercedes-Benz | ML500 | Rear Left, Rear Right | |
2000-2001 | Mercedes-Benz | ML55 AMG | Rear Left, Rear Right | |
1999-2001 | Mercedes-Benz | ML430 | Rear Left, Rear Right | |
1998-2003 | Mercedes-Benz | ML320 | Rear Right, Rear Left |
