Mazda (1.6, 1.8, 2.0) CV Axle Assembly - Front Left
Widget Didn’t Load
Check your internet and refresh this page.
If that doesn’t work, contact us.
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
32
Axle Nut Type
Hex
Compressed Length
610
Inboard Spline Quantity
26
Outboard Spline Quantity
26
ABS Tone Ring Tooth Quantity
44
Axle Nut Length
21
Axle Nut Thread Size
M22×1.5
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2002-2003 | Mazda | Protege | Front Left | |
2002-2003 | Mazda | Protege5 | Front Left | |
2001-2001 | Mazda | Protege | LX, DX, ES | Front Left |
1999-2000 | Mazda | Protege | Front Left |
