10-12 Hyundai Genesis Coupe CV Axle Assembly - Rear Left
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
31.5
Axle Nut Type
Hex
Compressed Length
801
Inboard Spline Quantity
28
Outboard Spline Quantity
30
ABS Tone Ring Tooth Quantity
47
Axle Nut Length
21
Axle Nut Thread Size
M22×1.5
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2010-2012 | Hyundai | Genesis Coupe | Rear Left |
