Hyundai (3.3) CV Axle Assembly - Front Left
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Thread Size
M22×1.5
Boot Color
Black
California Proposition 65
Yes
Inboard Joint Type
Male
Outboard Joint Type
Conventional
Prop 65 Yes/No
Yes
ABS Tone Ring Tooth Quantity
47
Axle Nut Length
1.02
Axle Nut Type
Hex
Boot Material
Neoprene
Compressed Length
26.06
Inboard Spline Quantity
28
Outboard Spline Quantity
30
Seal Diameter
2.56
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2011-2011 | Hyundai | Azera | GLS | Front Left |
2010-2010 | Hyundai | Sonata | Front Left | |
2010-2010 | Hyundai | Azera | Front Left | |
2009-2009 | Hyundai | Azera | GLS, Limited | Front Left |
2008-2009 | Hyundai | Sonata | GLS, Limited, SE | Front Left |
2007-2007 | Hyundai | Sonata | Limited, SE | Front Left |
2006-2006 | Hyundai | Sonata | Front Left | |
2006-2008 | Hyundai | Azera | Front Left |
