Chevrolet, Geo (1.3) CV Axle Assembly - Front Right
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
27
Axle Nut Type
Hex
Compressed Length
35.18
Inboard Spline Quantity
22
Outboard Spline Quantity
23
ABS Tone Ring Tooth Quantity
42
Axle Nut Length
22
Axle Nut Thread Size
M20×1.5
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2001-2001 | Chevrolet | Metro | Front Right | |
1999-2000 | Chevrolet | Metro | Front Right | |
1998-1998 | Chevrolet | Metro | LSi | Front Right |
1997-1997 | Geo | Metro | LSi | Front Right |
1995-1996 | Geo | Metro | Front Right |
