Chrysler, Dodge CV Axle Assembly
SPECIFICATIONS
ABS Tone Ring Included
NO
Axle Nut Length
21.5
Axle Nut Thread Size
M24×2
Boot Material
Neoprene
Inboard Joint Type
Female
Outboard Joint Type
Conventional
Axle Nut Included
Yes
Axle Nut Socket Size
36
Axle Nut Type
Hex
Compressed Length
22.24
Inboard Spline Quantity
29
Outboard Spline Quantity
33
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2007-2009 | Chrysler | Aspen | Front | |
2004-2009 | Dodge | Durango | Front |
