Chevrolet, Oldsmobile, Pontiac CV Axle Assembly - Front Left
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
36
Axle Nut Type
Hex
Compressed Length
20.59
Inboard Spline Quantity
34
Outboard Spline Quantity
33
ABS Tone Ring Tooth Quantity
47
Axle Nut Length
21.5
Axle Nut Thread Size
M24×2
Boot Material
Neoprene
Inboard Joint Type
Female
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
1991-1991 | Oldsmobile | Cutlass Supreme | International, Base | Front Left |
1991-1991 | Pontiac | Grand Prix | SE, GT, LE | Front Left |
1990-1991 | Chevrolet | Lumina | Base | Front Left |
1990-1990 | Oldsmobile | Cutlass Supreme | International, Base | Front Left |
1990-1990 | Pontiac | Grand Prix | LE, Mclaren | Front Left |
