01-06 Hyundai Santa Fe (2.4, 2.7 - FWD) CV Axle Assembly - Front Left
SPECIFICATIONS
ABS Tone Ring Included
Yes
Boot Color
Black
California Proposition 65
Yes
Inboard Joint Type
Male
Outboard Joint Type
Conventional
Prop 65 Yes/No
Yes
ABS Tone Ring Tooth Quantity
52
Boot Material
Neoprene
Compressed Length
25.55
Inboard Spline Quantity
27
Outboard Spline Quantity
27
Seal Diameter
2.36
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2001-2006 | Hyundai | Santa Fe | Front Left |
