CV Axle Assembly
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
32
Axle Nut Type
Hex
Compressed Length
32.32
Inboard Spline Quantity
26
Outboard Spline Quantity
28
ABS Tone Ring Tooth Quantity
44
Axle Nut Length
21
Axle Nut Thread Size
M22×1.5
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2007-2012 | Mazda | CX-7 | Rear Left |
