Countryside Road

Chrysler, Dodge (AWD) CV Axle Assembly - Front Right

Part Number:

203812

Product Type:

CV Components

SPECIFICATIONS

ABS Tone Ring Included

Yes

Axle Nut Included

Yes

Axle Nut Socket Size

31.5

Axle Nut Type

Hex

Compressed Length

23.9

Inboard Spline Quantity

24

Outboard Spline Quantity

27

ABS Tone Ring Tooth Quantity

48

Axle Nut Length

20.5

Axle Nut Thread Size

M22×1.5

Boot Material

Neoprene

Inboard Joint Type

Male

Outboard Joint Type

Conventional

FEATURES & BENEFITS

APPLICATIONS

Year Range
Make
Model
SubModels
Position
2017-2019
Dodge
Challenger
Front Right
2007-2020
Dodge
Charger
Front Right
2005-2020
Chrysler
300
Front Right
2005-2008
Dodge
Magnum
Front Right
