07-16 Ford Transit CV Axle Assembly
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
36
Axle Nut Type
Hex
Compressed Length
43.46
Inboard Spline Quantity
41
Outboard Spline Quantity
28
ABS Tone Ring Tooth Quantity
48
Axle Nut Length
17.5
Axle Nut Thread Size
M24×2
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2014-2016 | Ford | Transit | Front Right | |
2007-2012 | Ford | Transit | Front Right |
