Toyota (1.8) CV Axle Assembly - Front Left

202770

SPECIFICATIONS:

ABS Tone Ring Included

Yes

ABS Tone Ring Tooth Quantity

48

Axle Nut Included

Yes

Axle Nut Length

21

Axle Nut Socket Size

33.7

Axle Nut Thread Size

M22×1.5

Axle Nut Type

Bihexagonal

Boot Color

Black

Boot Material

Neoprene

Compressed Length

25.47

Inboard Joint Type

Male

Inboard Spline Quantity

20

Outboard Joint Type

Conventional

Outboard Spline Quantity

26

Year Range
Make
Model
SubModels
Position
2009-2019
Toyota
Corolla
Front Left
2009-2014
Toyota
Matrix
Front Left

Marketing Description:

GSP New CV Axle's are made from only the finest materials using premium steel, boot, and grease. GSP CV Axles are designed to exceed the original equipment specifications.for a trouble free ride.

AAIA Part Type Description:

CV Axle Assembly
