89-94 Subaru Justy GL CV Axle Assembly
SPECIFICATIONS
ABS Tone Ring Included
No
Axle Nut Length
0.51
Axle Nut Type
Hex
Boot Material
Neoprene
Compressed Length
22.05
Inboard Spline Quantity
23
Outboard Spline Quantity
27
Seal Diameter
1.97
Axle Nut Included
Yes
Axle Nut Thread Size
M20×1.5
Boot Color
Black
California Proposition 65
Yes
Inboard Joint Type
Female
Outboard Joint Type
Conventional
Prop 65 Yes/No
Yes
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
1994-1994 | Subaru | Justy | GL | Front Right, Front Left |
1991-1993 | Subaru | Justy | Front Left, Front Right | |
1990-1990 | Subaru | Justy | GL | Front Right, Front Left |
1989-1989 | Subaru | Justy | Front Left |
VIDEO
