Hyundai, Kia CV Axle Assembly - Rear
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
31.5
Axle Nut Type
Hex
Boot Material
Neoprene
Compressed Length
803
Inboard Spline Quantity
25
Outboard Spline Quantity
27
ABS Tone Ring Tooth Quantity
48
Axle Nut Length
21
Axle Nut Thread Size
M22×1.5
Boot Color
Black
California Proposition 65
Yes
Inboard Joint Type
Male
Outboard Joint Type
Conventional
Prop 65 Yes/No
Yes
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2010-2010 | Kia | Sportage | Rear | |
2005-2008 | Kia | Sportage | Rear | |
2005-2009 | Hyundai | Tucson | Rear |
