01-03 Mazda Protege (2.0 - FWD) CV Joint - Front Left Outer
SPECIFICATIONS
ABS Tone Ring Included
Yes
Boot Clamps Included
Yes
Boot Included
Yes
California Proposition 65
Yes
Inboard Spline Quantity
29
Joint Type
6 Balls
Outboard Spline Quantity
26
Prop 65 Yes/No
Yes
Shaft Length
93.5
Thread Size
M22×1.5
ABS Tone Ring Tooth Quantity
44
Boot Color
Black
Boot Material
Neoprene
Grease Included
Yes
Joint Length
59
Location
Outer
Overall Length
152.5
Seal Diameter
56
Snap Ring(s) Included
Yes
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2001-2003 | Mazda | Protege | Front Left Outer |
