Toyota Wheel Bearing and Hub Assembly - Rear
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Tone Ring
Bearing Type
Ball
Bolt Thread Pitch
M12X1.5
Brake Pilot Diameter
62
Flange Bolt Hole Quantity
4
Flange Diameter
152
Flange Offset
74.8
Spline Quantity
0
Wheel Stud Quantity
5
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
114.3
Bolts Included
No
Driven Type
Non-driven
Flange Bolts Included
No
Flange Included
Yes
Height
123.8
Wheel Pilot Diameter
60
Wheel Studs Included
Yes
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
1999-2003 | Toyota | Solara | Rear | |
1997-2001 | Toyota | Camry | Rear | |
1995-2004 | Toyota | Avalon | Rear |
