Countryside Road

Volvo (2.5 - AWD) Wheel Bearing and Hub Assembly - Rear

Part Number:

9336020

Product Type:

Hubs and Related Components

SPECIFICATIONS

ABS Tone Ring Tooth Quantity

-

Bearing Generation

Gen 3

Bolt Circle Diameter

108

Bolts Included

No

Driven Type

Driven

Flange Bolts Included

No

Flange Included

Yes

Hub Pilot Diameter

83

Anti Lock Braking System

No

Bearing Type

Ball

Bolt Thread Pitch

M12X1.5

Brake Pilot Diameter

63.5

Flange Bolt Hole Quantity

4

Flange Diameter

136

Flange Offset

63

FEATURES & BENEFITS

APPLICATIONS

Year Range
Make
Model
SubModels
Position
2005-2010
Volvo
S40
Rear
2005-2010
Volvo
V50
Rear
